Products Name:Type 113 mechanical seal

Products Details:Single ended / non balanced / fixed rotation, this series of seals are suitable for general corrosive chemical pumps, sewage pumps, industrial pumps, etc.. The movable ring adopts two forms of a pin pin or a fastening screw; the transmission is reliable; the axial dimension is short; the installation is convenient; the universal interchangeability is strong; and the utility model is suitable for viscous media.

Operating parameters:
Specification: 20 ~ 65mm, pressure = 1.2Mpa, temperature: -20 to 180 DEG C, line speed: less than 15m/s, axial momentum: + 0.5mm

Material combination:
Sealing face: graphite, silicon carbide, tungsten carbide, alumina, auxiliary sealing: Ding Jingjiao, fluorine rubber, ethylene propylene rubber, PRFE, metal components: 304 or 316L stainless steel
